Reverse Engineering
Scan-to-CAD reconstruction of physical parts — for modification, replication, and legacy part recovery.
From physical part to editable CAD
Reverse engineering converts a physical object into a parametric, editable CAD model using 3D scan data as the geometric reference. The result is a clean model that can be modified, scaled, or sent directly to production — without starting from scratch.
- Scan-to-CAD workflow
- Parametric solid reconstruction
- STEP, IGES & native format output
- Legacy part recovery
What we can help with
We handle the full workflow: scan the part, process the point cloud into a clean mesh, then reconstruct it as a parametric solid model (STEP, IGES, or native format). The process preserves critical features, mating surfaces, and dimensional intent.
Common use cases include recovering discontinued parts, enabling design modifications to existing products, and creating digital twins for manufacturing or inspection purposes.
